| printing standard screen |
| Post Date :2017-01-06 |
| Expire Date :2015-08-01 |
 View Basket |
| moq: 20pcs, technical parameter: 565,575,640,725,820,914,1018,1168,1206,1450,1620,1680mm, use for: textile printing, model: 60（60V），70（70V）,80(80V),100(100V)mesh |
| Detailed Trade Lead Description |
Note:specific specification can be produced according to customers requirements as well as can produce in line with customers extraordinary requirements.
|
Characteristic: Big hole,smooth slide,no chips at all,the sectionof the hole shows streamlined which is favorable for the flowing of dyestuff.More steady while printing single pattern,so can guarantee the printing effect,it also benefits to equipment maintenance,and avoids some color difference,used in printing all kinds of fiber and fabric in printing and dyeing industry.
目數(shù)(Mesh )
|
厚度(μm)
|
開(kāi)孔率(%)
|
孔徑(μm)
|
60
|
120
|
18
|
180
|
60V
|
|
18
|
180
|
70
|
125
|
22
|
179
|
70V
|
125
|
22
|
179
|
80
|
110
|
16
|
127
|
80V
|
110
|
16
|
127
|
100
|
105
|
13
|
92
|
100V
|
105
|
13
|
92
|
|
Notes:
1. All screen with "V" the hole order is 45 angle. Especially used in printing pane and line, geometrical figure, etc.
2. All kinds of screen can be used for 5~7 times repeatedly.
|
|
|
|
